Anti Climb Fence

Anti climb Fence – A More Rigid Security Fencing Than 358 Fence

  • Protects against cut-through
  • Increased delay factor
  • Excellent visibility
  • Vandal resistant
  • Compliments CCTV
  • Versatile (Anti-Climb & Anti Cut)
  • Cost effective

Product Details

Anti Climb Fence - A More Rigid Security Fencing Than 358 Fence

At YESON we design, build and install a security fence that fits your needs both visually and structurally. From wire mesh, iron, solid plate steel, vertical bars, brick, cement, pre cast or any other design, we specialize in constructing anti climb fencing that works.

Anti Climb fence is a custom fabricated security product that creates a visual screening and creates a protective barricade for a property needed to delay and deter a potential attack. The distinguishing feature of a mesh anti-climb fence is the anti-scale and anti-cut welded wire mesh fabrication. This makes it very difficult to get a foothold on this fence, and the cutting implements required to sever its welded heavy steel wire cannot fit into the minimal spaces of the mesh.

A vertical iron fence serves as a visual deterrent backed with heavy steel components that give a higher level of protection compared to the traditional chain link or architectural mesh fence alternatives.

anti-climbing-fence-drawing
ACF-01: Anti-climbing fence with double vertical wire design for high security perimeter fencing, available in black, dark green, brown, yellow colors.

High Security Anti-Climbing Fence Features

  • Good viewing visibility, it is a type of high security clear view fencing.
  • Welded well at each intersection.
  • Intrusion resistant, with extremely strong double vertical wire design.
  • Small mesh aperture, anti-cut, anti-climb, finger-resistant and toe-resistant.
  • Corrosion resistant with zinc aluminum alloy and PVC powder coating.
  • Surface finish after welding, every weld-point are protected well.
  • High strength with fully integrated with posts and anti-tamper fixings.
  • Fence security toppings are optional.
  • Easy for installation and free maintenance.
  • 5 year warranty.

Anti Climb Fence Specifications:

  • Wire: 4 mm steel wire.
  • Wire surface finish: galfan coating after welded, and then PVC powder coating (Min. 120 micron), or PVC powder painting.
  • PVC coated color: black, dark green, brown, yellow, desert sand, bronze or other colors request.
  • Mesh opening pattern: 70 mm × 8 mm, welded well at each intersection.
  • Mesh sheet width: 2515 mm.
  • Anti-climb mesh fencing panels and posts.
Table-1: anti-climb mesh fencing panels and posts specifications
Fence height (m)Panel size (Height × Width)Fence Post (Height × Size × Thick)Clamp Bar (Height × Width × Thick )Inter or corner Clamp No. (PCS)
2.02007 mm × 2515 mm2700 × 80 × 80 × 3 mm2007 × 60 × 5.00 mm7 or 14
2.42410 mm × 2515 mm3100 × 80 × 80 × 3 mm2400 × 60 × 5.00 mm9 or 18
3.03010 mm × 2515 mm3800 × 100 × 100 × 3.0 mm2997 × 80 × 6.00 mm11 or 22
3.63610 mm × 2515 mm4500 × 100 × 100 × 3.5 mm3607 × 100 × 7.00 mm13 or 26
Note: anti-climb mesh fencing can be custom ordered to measure.
  • Fence security toppings: Flat razor wire coils with barbed wire, concertina barbed wire, security fence spikes, or shark tooth spikes (coating according to the anti-climb fence panels).
    • Shark tooth spikes: width 35 mm, long teeth up to 58 mm.
    • Security anti-climb fence spikes:
      • Plate thickness: 2.0 mm
      • Base width: 65 mm.
      • Spike length: 35 mm short spikes, 70 mm long spikes.
      • Spikes pitch: 70 mm.
    • Razor wire
      • Style: flat razor wire or concertina razor wires.
      • Barb length: short barb or long barb.
      • Material: galvanised steel, stainless steel (for extremely corrosive environments).
      • Wire: high tensile 25 mm, aluminum/zinc wire, breaking load 7700 N.
      • Coil Diameter: 600 mm, 750 mm.
      • Number of loops: 55.
      • Extent length: 7.5 m.
    • Barbed wire
      • Galvanized and PVC coated barbed wire with 2 strands and 4 points.
      • Gauge of strand and barb wire: 11 gauge.
      • Barbs spacing: 3 inch.

Anti-climb fence with double vertical wire provides an ideal solution for high security perimeter and access control applications, such as:

  • Prison perimeter areas.
  • Military sites and government facilities.
  • Electricity distribution sites.
  • Airports, railways, roadways.
  • Seaports.
  • Fencing & intrusion detection projects.
  • Hydel power project.
  • Petroleum and chemical facilities.
  • Wildlife sanctuaries.
  • Warehousing facilities,
  • School.

High Security Anti Climb Mesh Fence price

  • The anti climb high security fence price is determined by the following aspects: raw material price, processing cost, and freight.
  • If your budget is limited, and the used environment requirements for corrosion and rust protection is not too high, for example in desert areas, you can choose Galfan coating without PVC coating.
  • If used in high corrosion and high humidity marine environment, then you must choose Galfan coating then PVC coating fence to meet the requirements. Of course, the price is higher than just galfan anti climb fencing.
  • In short, we recommend that you choose the most durable option within your budget.

Using double vertical wire welded anti-climbing fencing, say goodbye to intruders attempting to climb over your perimeter. Contact us now via [email protected] or fill the following from.
